Battery Management for Solar Powered Instrumentation
The Powerterm industrial grade Power supply/Battery back-up range from Omniflex has been standardised on by many major utilities around the world. It is the ideal solution where battery backup is necessary to ensure continuous operation of Dataloggers, RTU's, Remote Field Instrumentation and Remote Access Systems during power failures.
The PTS model, which forms part of the Powerterm range is a combined Solar Regulator and Power Supply System with integrated standby battery management, designed for small solar powered applications. The PTS allows connection of a solar panel (up to 140W) and a sealed lead acid battery to provide an industrial grade solar powered system, perfect for providing DC power to 12V or 24dc instruments where mains power supply is not possible.
The PTS has been designed to ensure that the battery, as well as the field instrument is well protected. These built in safety features include under-voltage cut-out, to protect the battery from deep discharge and fault protection, which disconnects the load/instrument when overcurrent fault condition is detected. The PTS also has a temperature sensor that compensates for changes in ambient temperature to keep the battery at its optimum.
The complete Powerterm range is specifically designed for industrial instrumentation applications and is well proven in RTU and remote standby applications exposed to harsh environments. Use of carefully selected long-life components and conservative design parameters combine to provide the complete compact PSU/battery back-up solution to depend on.
Other Omniflex Instrument Power Supply/Chargers Click Here to View more Details Copyright © 2016 Omniflex (Pty) Ltd, All rights reserved.
Key Features:
• Industrial Grade Power Supply with Battery Back-up/management
• Ideal for RTUs, dataloggers, remote field instrumentation,
alarm systems, remote access systems etc.
• Operates with up to 80W Solar Panel
• 12/24V Selectable
• DIN Rail or Surface Mount
Advantages:
• Under Voltage Cut-out protects batteries from deep discharge
• Over Current protection protects wiring against faults
• Charge Detect output
• Temperature compensation for optimum battery life
• Overcharging Protection
Benefits:
• Provide Continuous Power to Instruments in Remote Locations
• Proven in use in harsh environments
• Ease Of installation
• Built in Safety Features
• Increase Plant Safety
For further information, please contact us on:
sales@omniflex.com
or visit our website at www.omniflex.com
